Operating features – Wood’s Powr-Grip MRTA811LDC User Manual
Page 5
Rev 9.0/6-12
3
MRTA8-DC: #35075
OPERATING FEATURES
Note: Components featured in the following instructions for assembling, operating or
maintaining the vacuum lifter are underlined on their first appearance in each section.
Standard MRTA811LDC shown with 1-SCFM [28 liters/minute] vacuum generating system.
1 LIFT SPOOL
9 VACUUM GAUGE
17 PAD FRAME
2 LIFT BAR
10 AIR FILTER
18 HOIST PENDANT BASKET
3 BATTERY TEST BUTTON
11 VACUUM CONTROL VALVE
19 CONTROL HANDLE
4 BATTERY GAUGE
12 CONTROL HANDLE
20 LOW VACUUM WARNING LIGHT
5 POWER SWITCH
13 ROTATION RELEASE LEVER
21 Enclosure with BATTERY,
6 EXTENSION ARM
14 MOVABLE PAD MOUNTS
22 ... VACUUM PUMP and
7 BATTERY CHARGER
15 VACUUM PAD
23 ... VACUUM SWITCH
8 TILT LOCK (OPTION)
16 QUICK CONNECTORS
24 VACUUM RESERVE TANK
