Rev 0.0/8-13 4 LB7FAO2: #35069
OPERATION
Make sure that the adapted MRTA6-DC vacuum lifter is correctly installed on an appropriate
forklift, as directed in the preceding INSTALLATION section. When the lifter is installed on a
forklift, it should be able to tilt, rotate, and attach to or release loads just like a standard lifter.
Operate the lifter as directed in the OPERATION section of the lifter's instruction manual, but
substitute appropriate forklift functions whenever the lifter's instruction manual calls for the use
of a crane or hoisting equipment. Consult the forklift instructions as needed for further
information about its use.
Note: In addition to the WARNINGS stated in the preceding section and the MRTA6-DC lifter's
instruction manual, the operator must follow all statutory or regulatory requirements that relate
to the forklift when used in its geographical location (eg, OSHA Standard 1910.178 “Powered
industrial trucks” for forklifts used in the USA).
MAINTENANCE
When performing inspections and tests of the lifter as directed in the MAINTENANCE section of
the MRTA6-DC lifter's instruction manual, be sure to include all relevant parts of the Forklift
Adapter whenever applicable.
REPLACEMENT PARTS LIST
Stock No. Description Qty.
12826MM Flat Washer - 1/2" 8
12760 Lock Washer - 1/2" 8
11124 Hex Nut - 1/2-13 Thread 8
10858AM Bolt - 1/2-13 Thread x 4½" - Grade 5 - Full-Thread Type (aka fork securing screw) 4
10850AM Bolt - 1/2-13 Thread x 3½" - Grade 5 - Full-Thread Type (aka fork securing screw) 2
10846AM Bolt - 1/2-13 Thread x 3" - Grade 5 - Full-Thread Type (aka fork securing screw) 2
SERVICE ONLY WITH IDENTICAL REPLACEMENT PARTS
SUPPLIED BY OR APPROVED BY WOOD'S POWR-GRIP CO., INC.
