Specifications 59
Supported timing for HDMI (HDCP) input
Supported timing for Video and S-Video inputs
Resolution Mode
Refresh rate
(Hz)
Horizontal
frequency
(kHz)
Clock
(MHz)
720 x 400 720 x 400_70 70.087 31.469 28.3221
640 x 480
VGA_60 59.940 31.469 25.175
VGA_72 72.809 37.861 31.500
VGA_75 75.000 37.500 31.500
VGA_85 85.008 43.269 36.000
800 x 600
SVGA_60 60.317 37.879 40.000
SVGA_72 72.188 48.077 50.000
SVGA_75 75.000 46.875 49.500
SVGA_85 85.061 53.674 56.250
1024 x 768
XGA_60 60.004 48.363 65.000
XGA_70 70.069 56.476 75.000
XGA_75 75.029 60.023 78.750
XGA_85 84.997 68.667 94.500
1280 x 800 WXGA_60 59.81 49.702 83.5
1280 x 960
1280 x 960_60 60.000 60.000 108.000
1280 x 960_85 85.002 85.938 148.500
1280 x 1024
SXGA_60 60.020 63.981 108.000
SXGA_75 75.025 79.976 135.000
640 x 480@67Hz MAC13 66.667 35.000 30.240
832 x 624@75Hz MAC16 74.546 49.722 57.280
1024 x 768@75Hz MAC19 75.020 60.241 80.000
1152 x 870@75Hz MAC21 74.959 68.587 100.00
1440 x 900 WXGA+_60 59.887 55.935 106.50
1400 x 1050 SXGA+_60 59.978 65.317 121.75
1600 x 1200 UXGA 60.000 75.000 162.00
Video (HDCP)
480p 60 31.47 27
576p 50 31.25 27.000
720p_50 50 37.50 74.25
720P_60 60 45.00 74.25
1080i_50 50 28.13 74.25
1080i_60 60 33.75 74.25
1080p 50 56.25 148.5
1080p 60 67.5 148.5
Video mode
Horizontal
Frequency (kHz)
Vertical Frequency
(Hz)
Color sub-carrier
Frequency (MHz)
NTSC 15.73 60 3.58
PAL 15.63 50 4.43
SECAM 15.63 50 4.25 or 4.41
PAL-M 15.73 60 3.58
PAL-N 15.63 50 3.58
PAL-60 15.73 60 4.43
NTSC4.43 15.73 60 4.43
