HANDLES & CONTROLS
Footnotes:
TP 400-5144-3-WB-N
Manual No. 7006205 21" STEEL DECK EASY LINE
SERIES 0 & 1
5
Part No Description Item Qty Note
1A 7078247 1 HANDLE, Upper, Flat
1B 7300458 1 HANDLE, Upper, 22” Push
2 7300130 1 * PLATE, Control Panel
3 7100225 4 * SCREW, #8-16 Recessed Pan Head (Torxplus)
4 7028488 1 GUIDE, Rope (1/4-20 threads)
5 7076978 1 NUT, 1/4-20 Hex Nyloc
6 7090391 4 WASHER, 5/16 Internal Tooth Lock
7 7035744 4 KNOB, 5/16-18 Wing (Black)
7 M720727 4 KNOB, 5/16-18 Wing (Black) Briggs part
8A 7100069 1 ASS'Y, Control Head, Variable Speed (Incl. items 8-12, 15 & 16)
8B 7100254 1 ASS'Y, Control Head, Single Speed (Incl. items 8, 10, 12 & 15)
8 -- 1 * CASE HALF, Bottom, Black
9 -- 1 ** SPRING STEEL
10 -- 1 * CLUTCH LEVER, Silver
11 -- 1 ** ASS'Y., Speed Lever/Friction Material (Snapper) includes 7100412, Friction Strip
12 -- 1 * CASE HALF, Top, Variable Speed- Black
12 -- 1 * CASE HALF, Top, Single Speed- Black
13A 7078248 1 BAIL, Brake (self-propelled mower)
13B 7100845 1 BAIL, 22” (push-mower)
14 7100074 1 CABLE, Zone Control
14 7100641 1 CABLE, Zone Control used on SPV21E
15 7100263 1 * CABLE, Clutch
16 7100264 1 ** CABLE, Speed
17 7078246 1 HANDLE, Lower
18 7024649 2 WIRE TIE, 11 Inch Black Nylon
19 7091189 2 BOLT, 5/16-18 x 2” Curved Head Square Neck GR 2
20 7300103 2 BRACKET, Lower Handle, Black Textured
21 7091612 2 BOLT, Carriage 5/16-18 x 1-1/2”, GR 5
22 7090799 8 BOLT, Carriage 5/16-18 x 5/8”, GR 5
23 7091601 4 NUT, 5/16-18 Hex Flange Lock, GR 5
24 7100328 1 HOUSING, Snap-On E-Start
25 7028765 1 SWITCH, Electric Start (Start/Run)
26 7100329 1 NUT, 5/8-32 E-Start
27 7100330 1 CAP, E-Start
28 7011138 1 KEY, Ignition (Pair)
29 7091135 2 PUSHNUT, 3/8”
30 7100327 1 WIRING HARNESS, B&S
Note: * Used on self-propelled models only
Note: ** Used on variable speed models only
Note: Items 8 thru 12 are not available as individual parts.
