REAR WHEELS (Self-Propelled)
Footnotes:
TP 400-5144-3-WB-N
Manual No.
7006205
21" STEEL DECK EASY LINE
SERIES 0 & 1
15
Part No
Description
Item
Qty
Note
1A
7100184
2
ASSEMBLY, 9” x 2” Gear Wheel, LS Tread
w/powdered metal bushing
1A
7100175
2
ASSEMBLY, 9” x 2” Gear Wheel, LS Tread
w/nylon bushing
1B
7101104
2
ASSEMBLY, 9” x 2” Gear Wheel, Double Bar II Tread
w/nylon bushing
2A
7073618
1
BUSHING, Wheel (powdered metal)
part of item 7100184
2B
7024541
1
BUSHING, Wheel (nylon)
part of item 7100175
3
7014341
4
RETAINING RING
Waldes 5133-50
4
7024550
1
PINION, LH Drive
5
7024549
1
PINION, RH Drive
6
7026479
2
SEAL, Pinion (Felt)
7
7026478
2
RETAINER, Pinion Seal
8
7100644
2
WASHER, .531 x 1.25 x .06 thick
replaces 7091194
9
7078269
2
SHIELD, Dust
10
7900010
2
SNAP RING, 1-3/8”
Truarc 5100-137
11
7100626
2
O-RING, Buna N, 124
12
7090699
4
BOLT, 1/4-20 x 3/4” Hex Flange Lock
13
7078235
1
ASSEMBLY, Axle Arm, Left Rear
14
7078236
1
ASSEMBLY, Axle Arm, Right Rear
15
7100633
2
GRIP, Height Latch
replaces 7027702 (voided)
16
7100627
2
O-RING, Buna N, 018
17
7091192
2
WASHER, 1/2” Flat
18
7091193
2
COTTER, Hairpin
19
7100114
2
HUB CAP, 3-1/4” Diameter (black)
20
7018834
1
* CHARGER, Battery 120V/12V
21
7100794
1
* ADAPTER, Charger
22
7043977
2
* SCREW, #10-24 x 1/2” Pan Head Machine
included with battery
23
7015488
1
* WIRING HARNESS, Battery
included with battery
24
7100204
1
* BATTERY, 12V Sealed Lead Acid
includes 7015488, battery
harness
25
7090932
2
* NUT, #10-24 Square
included with battery
26
7900011
1
* SCREW 1/4-20 x 4” Hex Head Cap, GR 5
27
7091584
2
* NUT, 1/4-20 Hex Flange Lock
28
7300131
1
* BRACKET, Battery
29
7076978
1
* NUT, 1/4-20 Hex Nyloc
30
7024749
2
PAWL, 3/16” O.D.
31
7500041
2
ASSEMBLY, Axle Bearing
includes items 32 & 33
32
7078214
1
HOUSING, Axle Bearing
33
7078243
1
BALL BEARING, Axle
.50 I.D. x 1.125 O.D. x .3125
thick
34
7092016
2
* SCREW, 1/4-20 x 1-1/2” Hex Washer Self Tap
Note: * Used on electric start model only.
