4 5
Adjusting the Eyecup
The heavy duty folding flared rubber eyecup on the
Recon is designed to accommodate both eyeglass
weares and non-eyeglass wearers.
Carrying with the Clip
Depending on user preference,
the clip can be positioned in
several locations. This versatile
carrying option allows quick
attachment of the Recon to
MOLLE webbing, pocket edges,
equipment or other field
locations.
• The Recon features a winged
eyecup that blocks stray light
when fully extended.
• Fold the eyecup down when
viewing with eyeglasses.
Recon Tripod
The Recon comes with an ultra-compact field
tripod which may be used to steady the Recon while
observing or ranging small
objects. Thread the Recon
directly onto the tripod—
the flexible legs adapt to a
wide range of surfaces.
When not using the tripod, fold
the post of the Uni-Daptor alongside the length of
the Recon and continue viewing.
For added height and a quick-release option, attach
the Recon to the tripod with the quick-release
Uni-Daptor.
Post
Uni-Daptor
Base
Stud
1. Attach the base unit of the Uni-Daptor
to the tripod mounting plate.
2. Attach the post unit to the Recon
by threading the 1/4x20 stud into
tripod socket on the scope.
