Included with the Recon Scope
Rain/dust hood
Uni-Daptor tripod adapter
Tripod
Flip cap objective lens caps
Picatinny rail
Reticle Focus Wheel
Objective Lens
Image Focus Wheel
Winged Eyecup
Clip
Tripod Adapter
Socket
Basic Operation
Adjusting the Image Focus
Use the main focus wheel on the eyepiece to
obtain crisp, sharp images of objects at varying
distances. Designed
for quick single-handed
operation, simply place the
thumb and forefinger on
the focus wheel and turn
to move lens forward or
backward until the image is
as sharp as possible.
Adjusting the Reticle Focus
The reticle focus, located on the eyepiece next to
the eyecup, adjusts the sharpness of the reticle.
While looking at a blank
wall or blue sky, turn the
wheel until reticle is as sharp
as possible. Once set for a
particular user, that user will
not need to adjust the reticle
focus again. Accessories
Other accessories available from Vortex Optics
2x Doubler
killFLASH ARD
Lens cleaning kit
®
Rotate to focus image
Rotate to focus image
Low light polarizing filter
Extra Picatinny rail
Extra Uni-Daptor base
