Victorio VKP1009 Cherry Stoner - Manual (Page 5)

Assembly & Use Instructions
Please read all previous portions of the manual before assembling
your Cherry Stoner.
1. Insert the shaft into the underneath side of the Cherry Stoner and
push it up as far as it will go (see Diagram 1, below).
2. Slide the spring over the shaft. Then screw the knob onto the top of
the shaft (see Diagram 2, below).
3. Place the Cherry Stoner on a smooth surface and turn the suction
lever to secure the base (see Diagram 3, below).
4. Insert the gasket into the slot on the side of the body (see Diagram 4,
below).
5.
Slide the tabs of the pit container into the slots on the underneath side
of the Cherry Stoner (see Diagram 5, below).
6.
Place stemmed cherries in the tray. They will automatically funnel
through as you press down quickly on the knob, ejecting the pits into
the pit container below. The pitted cherries will roll out of the Cherry
Stoner, so be sure to have a bowl in place (see Diagram 6, below).
3
1
4 5
2
6
3
