Therma-Tru COMP 13 Weatherstrip and Door Bottoms - U1 Revised - Manual (Page 5)

Weatherstrip
and Door
Bottoms
Comp 13 2014 (U1 REVISED) 13.5
Door Bottoms - Sidelites
Inswing Sidelite Seat for
U1 Door Slabs
1"
2 1/8"
7/16"
Inactive Panel Door Bottom -
Composite Outswing Sill
SLAB SIZE LENGTH
10" SL 9-15/16"
12" SL 11-15/16"
14" SL 13-15/16"
2/0 23-15/16"
2/4 27-15/16"
2/6 29-15/16"
2/8 31-15/16"
2/10 33-15/16"
3/0 35-15/16"
3/6 41-15/16"
SI
D
E
L
IT
E
STAN
D
A
R
D
L
E
N
G
T
H
S
Inswing Sidelite Seat for
Standard Sidelite Slabs
SLAB SIZE LENGTH
10" SL 9-15/16"
12" SL 11-15/16"
14" SL 13-15/16" SI
D
E
L
IT
E
11/16"
2 1/8"
3/8"
1 5/32"
2 1/8"
3/8"
15/16"
1 13/32"
SLAB SIZE LENGTH
2/4 27-15/16"
2/6 29-15/16"
2/8 31-15/16"
2/10 33-15/16"
3/0 35-15/16" S
T
A
N
DA
R
D
L
E
NG
T
H
