DOOR PANELS
GASKETING,
WEATHERSTRIPPING
HINGES, STRIKES,
MULTI-POINT
LOCKING SYSTEM
FRAMES
SILL, SWING-IN, SWING
OUT, SIDELITE OPTIONS
TRANSOM OPTIONS
OPTIONAL
DECORATIVE PANELS
Factory-glazed: perimeter moldings flush with skin and made as integral part of skin.
Glass minimum 1/8-inch tempered, two panes with sealed airspace between typically
3/8-inch. Options for grooved, etched, Low-E, or grille between glass (GBG). Optional
removable wood grilles. Optional permanent external lite dividers.
Inserts (lites): perimeter frames in raised-molding patterns, molded from composite,
, paintable, screw-fastened to
doors, screw holes concealed with grained plugs in matching material.
Glass minimum 1/8-inch tempered, two es with sealed airspace between,
airspace typicall 3/4-inch.
Options for grooved etched .
Optional removable wood grilles.
wood-grained in natural hardwood patterns stainable or
Tested to
withstand high service temperatures resulting from exposure behind storm doors or dark
finishes.
pan
y 1/4-inch to
Low-E, grille between glass (GBG), or mini-blinds
Optional permanent external lite dividers.
Options for leaded decorative glass panel or
wrought iron grille in air space between tempered glass panes with brass, brushed nickel
or black nickel caming finishes. Wrought iron grille available in matte black only.
, ,
Jacketed thermoset open-cell foam, press-fit in kerfs at jamb stops in frames. Extruded
thermoplastic elastomer, finned and chambered design, press-fit into bottom kerf of
doors. Corner pads at bottom margin corners from jacketed thermoset open-cell foam.
Steel, with variety of finishes. Screws plated and finished to match hardware.
hinge size 4 x 4 x .098 inches. Strikes are proprietary adjustable type,
permitting in-out adjustment of door in frame, up to 3/16 inch.
a
Standard
Multi-point locking
system is available in manual shootbolt or tongue versions.
Milled from 5/4 kiln-dried pine, profiled with 1/2-inch stop, standard depth 4-9/16
inches. Other frame depths available to match wall constructions. Exterior casing
brickmould in WM180 pattern available. Optional frames in exterior grade red oak with
matching brickmould. Optional rot resistant jambs.
Wide range of sill options: fixed threshold, adjustable threshold, and public access
available in bronze, mill, satin nickel and brass finishes.
Double-door models: double door available with both leaves active and locking astragal
available.
Sidelite options: flush-glazed or lite insert models, with embossed panel & glass
moldings, in 10 inch, 12-inch and 14-inch widths. Sidelite systems available with
mullions separating doors from sidelites, and continuous sills and frame head, or as
separately framed and cased units joined together.
Transom frames, either rectangular, elliptical or half round, match door frames and have
matching exterior brickmould. Transom frames in primed pine or clear northern red oak
to match door frame option. Clear, Low-E, or etche
insulated glass. d Options for leaded
decorative glass panel or wrought iron grille in air space between tempered glass panes
with brass, brushed nickel or black nickel caming finishes. Wrought iron grille available
in matte black only.
OPTIONAL
FACTORY-GLAZED
GLASS OR GLASS
INSERTS
Fiber-Classic Door System Specifications
SPEC
Door System
Specifications
Product Manual 2
Faces: 1/16-inch minimum thickness, proprietary fiberglass-reinforced thermoset
composite, wood-grained in natural hardwood patterns, stainable and paintable. Door
edges:
machinable kiln-dried pine, primed , lock edge reinforced with engineered
lumber core, lockset area reinforced with solid blocking for hardware backup. Door
bottom edge:
moisture- and decay-resistant composite. Core: foamed-in-place
polyurethane, density 1.9 pcf minimum. Except where certification does not permit,
standard factory sizes may be end trimmed in shop or field to suit replacement door size
requirements.
Molded from composite, wood-grained in natural hardwood patterns, stainable or
paintable, screw-fastened to doors, screw holes concealed with grained plugs in
matching material.
