34
Excalibur ® P90 Zero Clearance Direct Vent Gas Fireplace
INSTALLATION
1) Open the bottom louver door. Loosen the 2 screws holding the Burner
ON/OFF switch and bracket to the bottom louver and lift the assembly
out.
2) Remove Arch Surround.
3) Remove glass door. Remove logs.
Note: The logs must not be in the unit.
4) Insert the back brick panel fi rst by carefully slipping it between the
back wall of the fi rebox and the rear log bracket.
5) Put the side panels in next. Slide them in from the front and push
them fl at up against the wall. Be very careful not to scratch them on
the fi rebox hardware.
6) Install the 2 brick retaining clips, one on each side.
Note:
If the bottom brick panel must be removed: Remove the Rear Log Stand,
then remove the Burner Tray. See the "Removing Valve" section.
OPTIONAL BRICK PANELS
