OPTIONAL EQUIPMENT, Continued

Backguard and Control Panel Features

Electrical Grounding Instructions: This Appliance must be properly
grounded and must be connected as shown in figure 1, 2 or 3 on page 11.
Do not alter wiring or electrical equipment.

The backguard equipment is optional, depending on model selection. The range you have
purchased may or may not be equipped with the features that are illustrated in this section.
The clocks have been placed into separate groups.

CLOCK WITH TIMER

To set a dial type clock, PUSH IN on the knob and turn it to the correct time.

(NOTE: Release and then without pushing in rotate so that the timer hand is “OFF.” This
should be done after setting the time.) To set timer don’t push in on the knob, simply rotate
to the length of time you want. A signal will sound when the time has elapsed. To stop the
signal rotate the knob to “OFF.”

DIGITAL CLOCK WITH TIMER

WARNING

!

To set “time of day” press CLOCK. Press ▲ or ▼ to set correct time.

To set “cook time” press TIMER (0:00 WILL APPEAR). Press ▲ to set minutes
(12 HRS IS MAXIMUM TIMER SETTING). Then press TIMER again.
Colon starts blinking indicating timer is counting down.

To clear timer press TIMER.

To return to clock while timer is running, Press CLOCK.

18

clock

horloge

timer

minuterie
