Spaulding Lighting RDIC with BOC - Manual (Page 4)

701 Millennium Boulevard Greenville, SC 29607 (864) 678-1000
BATTERY WIRING DIAGRAM-RDIC SHEET 4 OF 4
BLACK
WHITE
GREEN
RED
RED
YELLOW
YELLOW
BLUE
BLUE
CSS-UN42PS
Electronic Ballast
Emergency Ballast
FH4-DUAL-700L
Test Switch
Charging
Indicator
Light
Lamp-
holder
BLUE
BLUE / WHITE
YELLOW
YELLOW / BLACK
VIOLET +
BROWN -
RED
RED
WHITE
WHITE
RED
ORANGE 277V.
BLACK 120V.
RED RED
RED RED
RED
WHITE
CONNECT TO
APPROPRIATE
VOLTAGE LEAD.
INSULATE
UNUSED
LEAD.
BLACK
BLACK
WHITE WHITE
OPTIONAL SWITCH
OR OTHER
ON-OFF LAMP
CONTROL
BLACK
BLACK
Noir
WHITE
Blanc
GREEN
GREEN
Vert
GREEN
LABEL B
LABEL A
LUMINAIRE HOUSING
CUSTOMER WIRING
FIELD WIRING INCLUDES OPENING
THE LUMINAIRE AND CONNECTING
THE RED AND WHITE
BATTERY CONNECTION.
120V or 277V. Only
COM / NEUTRAL (N)
GROUND (G)
Battery Connector
BLACK
120V.
ORANGE
277V.
WARNING
POWER MUST BE OFF. RISK OF SHOCK
READ THOROUGHLY BEFORE INSTALATION
AVERTISSEMENT
L'ALIMENTATION DOIT ÊTRE COUPÉE. DANGER DE DÉCHARGE ÉLECTRIQUE
À LIRE ATTENTIVEMENT AVANT D'INSTALLER
SAVE THESE INSTRUCTIONS
http://www.spauldinglighting.com
