REV: A
INSTALLATION INSTRUCTION
Compact Wall Sconce Series
Consult Battery Wiring Diagram Included
WARNING
DISCONNECT POWER DURING INSTALLATION AND BEFORE SERVICING.
READ ALL INSTRUCTIONS COMPLETELY BEFORE STARTING INSTALLATION.
Figure 3
Figure 4
REV: A
REMARK: when user push the switch to bottom by hand
and then release, it will return to the top elastically and
it won't stay at the bottom.
Battery Connector, Normally open,
connect them after mounting the fixture;
