IN
CAR ADJUS
TMENTS
IN
CAR ADJUS
TMENTS
Get into car and buckle fully into the seat with seat belts. The head restraint
should fi t comfortably under the shoulder harnesses.
Seat the restraint against the shoulder belts by pulling up on the helmet
tethers, before they are hooked to the helmet. The device will rest against the
shoulder belts on the top, the seat in back and the driver’s shoulders.
The helmet tethers should be adjusted or changed to allow for no more than
2.25” of straight forward head movement. Measure from a resting position
(See Figure 13 dotted line) moving your entire head forward (not your chin to
your chest). You should still be able to rotate your chin to your chest.
Adjust the rear helmet tether fi rst; they are the PRIMARY RESTRAINT The tethers are easily
adjusted by unlacing the tether webbing through the 3-bar adjuster and lengthening or shortening
the tethers through the 3-bar adjustments.
The forward helmet movement can be checked by measuring the amount of forward movement as
the driver moves their head straight forward, with the chin up.
The tether adjustment is the measurement when the tethers fi rst have tension.
When the rear tether adjustments are complete make sure to lock down the tether by weaving
the webbing back through the adjuster one last time. Use the rubber O-ring to hold the excess
webbing in place.
IN CAR HELMET TETHER ADJUSTMENT
RESTRAINT TETHERS
ADJUSTABLE (SFI) TETHRS
1
2
3
4
5
6
7
Figure 13
no more than 2.25” of straight
forward movement
Helmet Tethers MUST be adjusted for proper fi t before use.
Helmet tether adjustment needs to be made with the driver seated and buckled into the vehicle with full gear
including, suit, helmet, and seatbelt harnesses.
