Schwank agroSchwank - Manual (Page 9)

GP-MAGR-BX-06A
agroSchwank / IN Manual
RD: Sept 2005
RL: 6
KH
Page 6
7A. TROUBLESHOOTING GUIDE
SET THERMOSTAT TO CALL FOR HEAT
IS THE HEATER BURNING?
THE SYSTEM IS WORKING PROPERLY.
STOP.
YES
NO
IS THERE LINE VOLTAGE TO
THE THERMOSTAT CONTROL? →CHECK CIRCUIT BREAKERS OR FUSE
→CHECK ON/OFF SWITCH
NO
YES
CONT’D
IS THERE A SPARK AT IGNITION
SPARK IGNITER?
→CHECK SPARK IGNITER CERAMIC FOR
CRACK, REPLACE SPARK IGNITER IF NECES
SARY
→CHECK HI-VOLTAGE WIRE C O N N E C T I O N
FROM SPARK IGNITER TO IGNITION MODULE
→ENSURE HIGH VOLTAGE S P A R K
I S
GENERATED AT THE IGNITION CONTROL
TERMINAL BY FOLLOWING THE STEPS AS
SHOWN BELOW:
-SHUT OFF ELECTRICAL POWER
-REMOVE THE HI-VOLTAGE WIRE ON THE
IGNITION CONTROL TERMINAL
WARNING: BEFORE REMOVING HI-VOLTAGE
WIRE, ELECTRICAL POWER TO THE SYSTEM
MUST BE SHUT OFF. THIS TERMINAL CARRIES
15,000 AC VOLTS.
• TURN ON ELECTRICAL POWER
• PLACE A METAL CONDUCTOR 1/8" AWAY
FROM THE HI-VOLTAGE TERMINALS
WARNING: THE HANDLE ON THE METAL
CONDUCTOR MUST BE HEAVILY INSULATED.
A LONG SCREW DRIVER WITH THICK PLASTIC
INSULATION HANDLE IS IDEAL FOR THIS
APPLICATION.
• IF NO SPARKING OCCURS ACROSS THE
GAP TO THE METAL CONDUCTOR, THEN
THE IGNITION CONTROL IS DEFECTIVE.
REPLACE WITH NEW IGNITION CONTROL. -
SHUT OFF ELECTRICAL POWER AND RE-
CONNECT THE HI-VOLTAGE WIRE.
NO
