Schwank STR-USA User Manual
Page 3
SP-MSTR-AU-05A
STR Manual
RD: NOV, 2003
RL: 5
KH
STR GARAGE & WORK SHOP
INFRA-RED GAS TUBE HEATERS
TABLE OF CONTENTS
TOPIC PAGE NUMBER
1. GENERAL .............................................. 1
2. INSTALLATION IN GARAGES ... ...... 2
3. PRE-INSTALLATION SURVEY ... ...... 2
TUBE KIT MATRIX ....................... ...... 2
4. MOUNTING CLEARANCES ................ 2
5. SYSTEMS INCORPORATING 90
DEGREE BENDS AND 180-DEGREE
ELBOWS ......................................... ...... 4
6. GENERAL INSTALLATION
INSTRUCTIONS ............................. ...... 5
7. SUSPENSION SYSTEM ................. ...... 7
8. FLUE VENTING .................................. 11
9. COMBUSTION AIR DUCT.....….… .. 14
TOPIC PAGE NUMBER
10. GAS SUPPLY INSTALLATION .......15
11. ELECTRICAL AND
THERMOSTAT WIRING ..................16
12. OPERATING SEQUENCE .................17
13. LIGHTING INSTRUCTION……….. 18
14. RECOMMENDED
MAINTENANCE ................................18
15. WIRING DIGRAMS ...........................19
16. TROUBLESHOOTING
GUIDES ...............................................20
17. SPARK IGNITION CIRCUIT ............22
18. START UP SHEET .............................23
19. OPTIONAL COMPONENTS .............25
20. LIMITED WARRANTY .....................28
