InfraSave IEP-4024 Manual
Heat Lamp Replacement : … continued
Step 14
Remove the heat lamp retainer clips both ends of lamps.
 One clip at each end of heater
 Two clips in the center of heater
Step 15
IMPORTANT: Wear gloves to handle the heat lamp.
Oils from your skin will damage the lamp.
The heat lamp is VERY FRAGILE - HANDLE AND ASSEM-
BLE WITH GREAT CARE!
Carefully slide old heat lamp out of heater through rectan-
gular slot in end of reflector.
CAREFULLY install new heat lamp and clip in place.
Reverse steps above to reassemble the heater.
Take particular care not to damage the lamp at Step 14 and Step 13.
