ecoSchwank-X / IL-X MODELS
ITEM
1
BURNER BODY ~ INCLUDES TILES MOUNTED IN BODY
JX-X025-BO
ECO-X 6 / IL-X 25: BODY + Mounted TILES
JX-X037-BO
ECO-X 10 / IL-X 37: BODY + Mounted TILES
JX-X050-BO
ECO-X 13 / IL-X 50: BODY + Mounted TILES
JX-X075-BO
ECO-X 18 / IL-X 75: BODY + Mounted TILES
JX-X100-BO
ECO-X 26 / IL-X 100: BODY + Mounted TILES
JX-X150-BO
ECO-X 32 / IL-X 150: BODY + Mounted TILES
JX-X200-BO
ECO-X 52 / IL-X 200: BODY + Mounted TILES
2
MAIN BURNER ORIFICE - See chart below
3
VENTURI AERATION RESTRICTOR PLATE (AIR THROTTLE) - See chart below
ORIFICE & AIR THROTTLE CHART - ecoSchwank-X / IL-X
Input (Btuh)
Orifice Part #
Air Throttle Part #
Orifice Part #
Air Throttle Part #
21,500
JX-0748-DM
JL-0764-XX
JX-0755-DM
JL-0764-XX
34,000
JX-0741-DM
JO-0373-CC-
JX-0752-DM
JO-0373-AA-
50,000
JX-0731-DM
JO-0373-XX-
JX-0747-DM
JO-0373-XX-
71,500
JX-0729-DM
JO-0375-XX-
JX-0742-DM
JO-0379-XX-
100,000
JX-0719-DM
None
JX-0733-DM
None
150,000
2 x JX-0729-DM
2 x JO-0375-XX-
2 x JX-0742-DM
2 x JO-0379-XX-
200,000
2 x JX-0719-DM
None
2 x JX-0733-DM
None
4
JX-0210-XX
ORIFICE HOLDER - ALL MODELS - ALL SIZES
5
1", 2" & 2.5" Pipe Nipple - Available at any supply house
6
COMBINATION GAS VALVE
JL-0701-XX
ECO-X & IL-X N.G. (ALL SIZES)
JL-0703-LF
ECO-X 6 & IL-X 25: 21,500 Btuh L.P. Gas
JL-0703-XX
ECO-X & IL-X L.P. Gas (ALL SIZES EXCEPT 21,500 Btuh)
7
JX-0206-XX
CONTROL BRACKET - ALL MODELS AND SIZES
8
DIRECT SPARK IGNITION CONTROL
JX-0202-XX
HONEYWELL S87C D.S.I. CONTROL
JX-0202-EK
JX-0201-DD-
10
BAFFLE ASSEMBLY - welded integral part - replace burner body if defective
11
GASKET SET
JX-0245-AA
ECO-X 6 & IL-X 25
JX-0245-XX
ECO-X 10 & IL-X 37
JX-0246-XX
ECO-X 13 & IL-X 50
+ 11a
JX-0247-XX
ECO-X 18, 36 & IL-X 75, 150 (INCLUDES 11A)
+ 11a
JX-0248-XX
ECO-X 26, 52 & IL-X 100, 200 (INCLUDES 11A)
12
JO-0370-CX
CERAMIC TILE - ALL MODELS - ALL SIZES
13
Integral tile support - welded to body - not replaceable
PART DESCRIPTION
PART NUMBER
Propane Gas
Gas Type ->
REPLACEMENT KIT FOR SYNETEK 3 TRY IGNITION CONTROL - HONEYWELL
S87C
DSI - FENWAL - TWO BURNER: ECO-X 36, 52 & IL-X 150, 200;
Also Includes Wire Harness JX-0201-WH
ECO-X 6 / IL-X 25
ECO-X 10 / IL-X 37
Model
Natural Gas
ECO-X 52 / IL-X 200
ECO-X 13 / IL-X 50
ECO-X 18 / IL-X 75
ECO-X 26 / IL-X 100
ECO-X 36 / IL-X 150
ECO-X_IL-X_2009_RPL.2
Page 3
GP-RECX-CX-04F
ECO/X IL/X RPL
RD: JAN 2013
RL: 4F
