4
17. Attach an S&S® air cleaner cover or the stock Harley-Davidson®
Twin Cam 88®, 96™, or 103™ air cleaner cover to the stealth air
cleaner kit by installing the 5/16" button head screw with 243 blue
Loctite applied to the threads and torque to 10 ft.-lbs.
18. On 2001 and later fuel injected bikes apply the included label
containing the EO number to the frame down tube above or below
the factory label. Do not cover up any portion of the factory label.
Picture 12
CARB label here
5/16" Button Head Cover Screw
Picture 10
1
2
3
4
8
8
7
5
6
7
9
5
5
1. Screw, SHCB, 5/16-18 x .500", Polished, Stainless Steel .. 500-0051
2. Screw, SHC, Flanged Button, ¼-20 UNC x .750"
(Each) 2 required ............................................................................... 500-0060
3. Plate, Top, Air Filter, Molded, Plastic ...................................170-0026
4. Filter, Air, Tapered, Standard Pleated, 5.500" x 6.000"x 2.375",
Cotton, Stealth Air Cleaner Kit ..............................................170-0043
5. Screw, SHCB, ¼-20 UNC X .825" (Each) 3 required ................ 500-0059
6. Backplate, Air Cleaner, Machined, Stock CV & EFI, Black, Die Cast,
1991-up xl .....................................................................................170-0048
7. Screw, Backplate Vent, SHCB, ½-13 x 1-½", Polished,
Stainless Steel (Each) 2 required .................................................170-0044
8. Washer,Flat,.520" x .880" x .024",Nitrile Rubber Coated,
Cold Rolled Steel (Each) 8 required ................................................50-7055
9. Gasket,Backplate,1991-up xl/bt ...........................................106-6022
S&S Stealth Air Cleaner Kit for 1991 and Up Harley-
Davidson® Sportster® with Stock CV Carburetor and
Stock EFI System
