Installation Details
The following drawings illustrate common construction details for residential wall assemblies using the
products and building science information provided in this guide. The drawings are not project-specific
and, of course, are meant to be modified by the project architect to include selected cladding, structural,
and other construction materials. Each drawing, however, clearly labels assembly elements by function
and a narrative description of each detail is included.
The following details are included in this guide:
01.
“Thick ci” Cladding Attachment System
02.
Foundation-to-Wall Interface
03.
Floor Slab-to-Wall Interface
04.
Inside Corner – Horizontal Section
05.
Outside Corner – Horizontal Section
06.
Punched Window Interface – Installation Sequence
07.
Wall-to-Balcony Interface
08.
Wall-to-Roof Interface
