1 Outline of the Product 1-1. Preface
- 3 - RM-5000 Multi-unit Case
1
Outline of the Product
1-1. Preface
Thank you for choosing our multi-unit case* "5000-XXY" model for use with the RM-5000 series.
• The multi-unit case comes in the following models with different specifications:
5000-XX Y W: Wall mounting type
R: Rack mounting type
02: 2-point model
04: 4-point model
06: 6-point model
08: 8-point model
10: 10-point model
12: 12-point model
This manual explains how to use the multi-unit case and its specifications.
It contains information required for using the multi-unit case properly. Not only the first-time users but also
the users who have already used the product must read and understand the operating manual to enhance
the knowledge and experience before using the multi-unit case.
1-2. Purpose of use
{
The multi-unit case is a multi-point unit for use with the RM-5000 series. The multi-unit case, having a
power supply unit, is ready for instrumentation only by connecting the commercial power supply,
mounting an indicator/alarm unit (option) and buzzer unit (option), and connecting a detector head
(option) to it.
{
Various indicator/alarm units of the RM-5000 series can be laid out in a desired way.
