65-2399RK-CH4 Combustible Gas Transmitter • 17
4. Turn the regulator’s on/off knob clockwise to close the regulator.
5. Unscrew the regulator from the calibration cylinder.
Returning to Normal Operation
1. Remove the voltmeter leads from the amplifier test points.
2. Unscrew the calibration cup from the detector.
NOTE: For convenience, leave the regulator and calibration cup connected by the
sample tubing.
3. Secure the junction box cover to the junction box.
4. When the controller display reading falls below the alarm setpoints, return the
controller to normal operation.
5. Verify that the controller display reading decreases and stabilizes at 0 %Vol.
6. Store the components of the calibration kit in a safe and convenient place.
Parts List
Table 6 lists replacement parts and accessories for the methane transmitter.
Table 6:Parts List
Part Number Description
06-1248RK Sample tubing (3/16 in. x 5/16 in.; specify length when ordering)
18-0400RK-01 Junction box with spacers
33-0157RK Hydrophobic disk membrane for detector cap
57-1053RK Amplifier with gasket (specify detector part number when ordering)
61-0199RK-CH4 Infrared CH
4
%Vol. detector
61-5041RK-CH4 Infrared CH
4
replacement plug-in sensor
65-2399RK-CH4 Methane transmitter (includes detector, junction box, and amplifier)
71-0201RK 65-2399RK-CH4 Methane Transmitter Operator’s Manual (this document)
81-0013RK-01 Steel calibration cylinder, 50% Volume methane in nitrogen, 34-liter
81-0076RK-01 Steel calibration cylinder, zero emission air, 34-liter
81-1050RK Regulator, 0.5 liter/minute; with pressure gauge and flow control knob, for 17 liter and
34 liter steel calibration cylinders
81-1103RK Calibration cup
82-0006RK Pot adjust screwdriver, for calibration
