Description, Zero pot, Figure 1: co transmitter component location – RKI Instruments 65-2336RKSS User Manual
Page 6
2 • 65-2336RKSS CO Transmitter
Description
This section describes the components of the CO transmitter. The CO transmitter is a 4 to
20 mA type detector head. It consists of the CO detector, amplifier, and junction box.
Figure 1: CO Transmitter Component Location
Span Pot
Factory Adjust Pot
100mV - 500mV
Range - Test Point (Black)
+ Test Point (Red)
S
SPA
N
T
O
X
IC
O
X
Y
Zero Pot
SI
G
/P
W
R
ZE
R
O
Controller
Terminal
Strip
Amplifier
Detector
Terminal
Strip
J-Box
CO
Detector
