65-2320RK-100 Oxygen Transmitter • 13
Returning to Normal Operation
1.
Remove the voltmeter leads from the amplifier test points.
2.
Secure the junction box cover to the junction box.
3.
When the controller display reading rises above the decreasing alarm setpoint, return
the controller to normal operation.
NOTE:
If you do not allow the gas reading to increase above the decreasing alarm point,
then unwanted alarms may occur.
4.
Verify that the controller display reading increases and stabilizes at 20.9% volume.
5.
Store the components of the calibration kit in a safe and convenient place.
Parts List
Table 3 lists replacement parts and accessories for the oxygen transmitter.
Table 3: Parts List
Part Number
Description
06-1248RK-03
Calibration kit sample tubing, 3 foot length
18-0400RK-01
Junction box with rubber spacers
57-1064RK-02
S2 series oxygen amplifier, w/orienting gasket, 0 - 100%
65-2320RK-100
Oxygen transmitter, non-explosion proof, includes detector
65-2510RK
Replacement oxygen detector, non-explosion proof
71-0174RK
65-2320RK-100 Operator’s Manual (this document)
81-0076RK
Zero air calibration cylinder, 17 liter steel
81-0076RK-01
Zero air calibration cylinder, 34 liter steel
81-0076RK-03
Zero air calibration cylinder, 103 liter steel
81-0078RK
100% nitrogen calibration cylinder, 17 liter steel
81-0078RK-01
100% nitrogen calibration cylinder, 34 liter steel
81-0078RK-03
100% nitrogen calibration cylinder, 103 liter steel
81-F301RK
Calibration kit for oxygen detector head, 103 liter
81-F301RK-LV
Calibration kit for oxygen detector head, 34 liter
81-1050RK
Regulator with gauge and knob, 0.5 LPM, for 17 liter and 34 liter steel calibration cylinders
81-1051RK
Regulator with gauge and knob, 0.5 LPM, for 34AL/58/103 liter calibration cylinders
81-1117RK
Calibration cup
