background image

61-1006RK/61-0192RK Combustible Gas Detector • 1

Overview

This manual describes the 61-1006RK combustible gas detector. This manual also
describes how to install, start up, maintain, and calibrate the detector when used with a
gas monitoring controller. A parts list at the end of this manual lists replacement parts and
accessories for the combustible gas detector.

The 61-1006RK combustible gas detector includes a junction box. This manual may also be
used for the 61-0192RK combustible gas detector which does not include a junction box
and is normally mounted in one of a controller’s conduit hubs. If you are using a
61-0192RK combustible gas detector, disregard all references to the junction box and
junction box terminal block.

Specifications

Table 1 lists specifications for the combustible gas detector.

WARNING: When using the 61-1006RK/61-0192RK, you must follow the instructions

and warnings in this manual to assure proper and safe operation of the
61-1006RK/61-0192RK and to minimize the risk of personal injury. Be sure
to maintain and periodically calibrate the 61-1006RK/61-0192RK as
described in this manual.

Table 1: 61-1006RK Specifications

Target/Calibration Gas

With Junction Box
61-1006RK-CH4: Methane

Without Junction Box
61-0192RK-CH4: Methane

Area Classification

Explosionproof for Class I, Groups B, C, and D

Sampling Method

Diffusion

Detection Range

0 to 100% volume

Response Time

90% in 45 seconds

Accuracy

± 5% of reading or ± 2% of full scale (whichever is greater)
