Noise data for UR 2:
Noise measurement to DIN 45635-31-01-KL3
Sound power level L
WA
= 86 dB(A)
Workplace related emission level L
p eq
= 80 dB(A)
Service conditions:
Cleaning fluid: water
Filling: 100%
Object to be cleaned: Analysis sieve 400x65
Wear ear protectors when working continuously within a radius of 2
m around the ultrasonic unit to protect your health!
Rated voltage
See type plate on rear of machine
HF frequency
35 kHz
Capacities
UR 1 = 5.7 l
UR 2 = 42 l
Current consumption
UR 1 = 0.5 A
UR 2 = 1.3 A
Fuses
UR 1 = F2A / 250V
UR 2 = F4A / 250V
Dimensions
UR 1 :
Height: approx. 260mm x 260mm // Weight: approx. 5 kg
Internal vibrating trough = 245 mm x H 130 mm
UR 2 :
Height: approx. 460mm x 570mm // Weight: approx. 21 kg
Internal vibrating trough = 515 mm x H 200 mm
Mounting surface required
UR 1 :
260 mm x 260 mm; no safety clearances necessary.
UR 2 :
570 mm x 570 mm; no safety clearances necessary.
