Part numbers are required when ordering parts.
C a b l e L i s t
A c c e s s o r i e s L i s t
KEY# QTY PART# DESCRIPTION
KEY# QTY PART# DESCRIPTION
AB CRUNCH HARNESS
ANKLE STRAP
LAT BAR
LOW ROW BAR
LAT BAR PAD
FOAM GRIP 1 1/2” OD X 6 3/4” L (multi hip)
FOAM GRIP 1 1/2” OD X 8 1/2” L (low row bar)
FOAM GRIP 1 1/2” OD X 13” L (seated press)
FOAM GRIP 1 1/2” OD X 21” L (lat bar)
JACH
JAS
JLB
JLRB
JBP
JFG1.5X6.75
JFG1.5X8.5
JFG1.5X13
JFG1.5X21
27
28
115
116
117
118
119
120
121
1
1
1
1
2
2
2
2
2
37
38
39
40
1
1
1
1
JHPC3916
JLPC9120
JSC757
JMHC1790
HIGH PULLEY CABLE 12’ 10” (3916mm)
LOW PULLEY CABLE 20’ 9” (6120mm)
SHORT CABLE 2’ 5” (757mm)
MULTI HIP CABLE 5’ 10” (1790mm)
G 2 B H a r d w a r e
( c o n t i n u e d )
KEY# QTY PART# DESCRIPTION
106
108
109
110
111
113
122
123
124
125
126
127
128
129
130
131
132
133
134
135
137
2
4
2
1
1
2
2
2
2
4
2
2
2
4
4
4
4
2
2
2
2
JTSPP3
JAB.37X.62FT
JS.12X.38FT
JFHPP3.5
JFHPP6.75
JRS2.5
JACN.19
JJN.37
JBB.5X.87
JBB.75X1
JBB1X1.5
JRR1.25X1.5
JCC1X1.37
JBB1X1.75
JBB.5X.87
JBB.37X.87
JBB.75X1
JWW.75
JBB1X1.5
JSB1X1.37
JFLTW.12
T-SHAPED POP PIN 3” (back pad and seat pad)
ALLEN BOLT 3/8” X 5/8” FULL THREAD
SCREW 1/8” X 3/8” FULL THREAD
FLAT HEAD POP PIN 3 1/2” (seated press)
FLAT HEAD POP PIN 6 3/4” (multi hip)
RUBBER STOP 2 1/2” L (3/8” bolt)
ACORN CAP NUT 3/16” ID preinstalled
JAM NUT 3/8”
OILITE BUSHING 1/2”IDX 7/8”OD (back pad adjuster)
OILITE BUSHING 3/4”ID X 1”OD (multi hip)
OILITE BUSHING 1”ID X 1.5”OD (multi hip)
RETAINING RING 1 1/4”ID X 1.5”OD
CHROME COLLAR 1”ID X 1 3/8”OD
OILITE BUSHING 1”ID X 1 3/4”OD preinstalled (press arm pivot)
OILITE BUSHING 1/2”ID X 1 7/8”OD preinstalled (press arm pivot)
OILITE BUSHING 3/8”ID X 7/8”OD preinstalled (left and right pivot)
OILITE BUSHING 3/4”ID X 1”OD preinstalled (left and right junction)
WAVE WASHER 3/4”ID X 1”OD
OILITE BUSHING 1”ID X 1 1/2”OD preinstalled (left and right junction)
STEEL BUSHING 1”ID X 1 3/8” preinstalled (seated press arm support)
WASHER 1/8” (cup holder)
