246
RECTANGULAR CONNECTORS GDM-SERIES
Type B EN 175301-803 (DIN 43650) / ISO 6952 > Cable socket with electronic insert
Order No.
Product description
Other standard types
Number of contacts
Cable gland
Cable diameter
Conductor size
Standard
Housing Color
Construction type
Description of Wiring
LED color
Voltage rectifier
Suppressor
Other characteristics
Drawing
Technical data
Pin dimensions
Rated voltage
Rated current
Contact resistance
Type of termination
Suitable cables
Mounting
Material
Contact surface material
Contact bearer material
Housing material
Environmental conditions
Protection class (IEC 60529)
Pollution severity
Temperature range
Inflammability class
Housing
Contact bearer
Approvals
UR
Packing unit
Packaging unit
Scope of delivery and accessories
Accessories to order separately
Type GMNL 216 NJ LED 24 HH schwarz/black GMNL 209 NJ GB1 LED 24 schwarz/black
934 460-002
function indicator (LED) with protective circuit
(diode)
transparent housing,
cable gland grey: Order No. 934 460-003
2 + PE
M12 (black)
6.5 mm
max. 1.5 mm2
DIN EN 175 301-803-B
transparent
B
LED red
diode
1
2
RD
6.3 mm x 0.8 mm
DC 24 V
8 A
≤ 4 mOhm
screw / cable shoe / cable eye
4.5 mm to 10 mm diameter
central screw
Sn
PA
PA
IP 65
3
-40 °C to +90 °C
94 V-1
94 HB
in preparation
50 pieces
(NBR) flat gasket GMN 209-3,
Order No. 733 273-002;
knurled screw GDM 3011-8,
Order No. 732 574-001;
stainless steel screw GDM 3011 RF-1,
Order No. 734 363-001
933 400-100
Bridge-type rectifier with protective circuit (vari-
stor) and function indicator (LED)
transparent housing,
cable gland grey: Order No. 933 400-106
2 + PE
PG 9 (black)
6.5 mm
max. 0.75 mm2
DIN EN 175 301-803-B
transparent
B
LED red
bridge-type rectifier
Varistor
(+)
(–)
1
2
~
~
u
RD
6.3 mm x 0.8 mm
AC/DC 24 V
2 A (SEV 1011 : 1,5 A) AC / 1 A DC
≤ 4 mOhm
screw / cable shoe / cable eye
4.5 mm to 7 mm diameter
central screw
Sn
PA
PA
IP 65
3
-40 °C to +90 °C
94 V-1
94 HB
UR
50 pieces
(NBR) flat gasket GMN 209-3,
Order No. 733 273-002;
knurled screw GDM 3011-8,
Order No. 732 574-001;
stainless steel screw GDM 3011 RF-1,
Order No. 734 363-001
