11|27
RoHS compliant
RJ45-IP67 Industrial Ethernet Connector System
Description
Order data
Product drawing
Accessories and Installation tools
For RJ45 products
RJ45 plug connector Cat. 5e or 6A shielded
Grommets, Color: black, blue, green, yellow, red or white
RJ45 plug connector crimp tool
Insertion tool for RJ45 IDC version
Cable tester
RJ45 Cat.5e or 6A Plug connector, shielded Grommets
Multi-Modular cable tester Insertion toll for RJ45 IDC version RJ45 plug connector crimp tool
Accessories/Tools Part Number
black Part Number
blue Part Number
green Part Number
yellow Part Number
red Part Number
white Part Number
Grommet 795-601302 795-601303 795-601304 795-601305 795-601306 795-601307
RJ45 Cat. 5e Plug connector, shielded 391J00039X
RJ45 Cat. 6A Plug connector, shielded 391J00049X
Crimp tool for RJ45 plug connector 360X30029X
Insertion tool for RJ45 insulation
displacement terminatin version (IDC)
360X30049X
Cable tester 360X30039X
