background image

11

MBG Series

Crimp contacts

(1) contact reeled (2) loose contact

Exemple:

RM20M13K

- Size #16, Machined, AWG22 wire.

Contact

size

Type

Wire size

Part number

Max

wire Ø

Max

insulator Ø

Plating

available

AWG

mm²

Male

Female

#16

Ø1.6

mm

Machined

30-28

0.05-0.08

RM28M1-

RC28M1-

0.55

1.1

K, J

Machined

26-24

0.13-0.2

RM24M9-

RC24M9-

0.8

1.6

K, J

Stamped &

Formed

26-24

0.13-0.25

SM24M1-

(1)

SM24ML1-

(2)

SC24M1-

(1)

SC24ML1-

(2)

0.89-1.28

Insulation

grip

S31, S18, TK6

Machined

22-20

0.32-0.52

RM20M13-

RC20M13-

1.18

1.8

K, J

RM20M12-

RC20M12-

2.2

Stamped &

Formed

22-20

0.35-0.5

SM20M1-

(1)

SM20ML1-

(2)

SC20M1-

(1)

SC20ML1-

(2)

1.17-2.08

Insulation

grip

S31, S18, TK6

Machined

20-16

0.52-1.5

RM16M23-

RC16M23-

1.8

3.2

K, J

Stamped &

Formed

18-16

0.8-1.5

SM16M1-

(1)

SM16ML1-

(2)

SC16M1-

(1)

SC16ML1-

(2)

3.0

No insulation

grip

S31, S18, TK6

Stamped &

Formed

18-16

0.8-1.5

SM16M11-

(1)

SM16ML11-

(2)

SC16M11-

(1)

SC16ML11-

(2)

2.0-3.0

Insulation

grip

S31, S18, TK6

Machined

16-14

1.5-2.5

RM14M50-

RC14M50-

2.05

3.2

K, J

Machined

16-14

1.5-2.5

RM14M30-

RC14M30-

2.28

3.2

K, J

Stamped &

Formed

14

2.0-2.5

SM14M1-

(1)

SM14ML1-

(2)

SC14M1-

(1)

SC14ML1-

(2)

3.2

No insulation

grip

S31, S18, TK6

Standard version
