UTS Hi seal
UTS : Your first choice in waterproof connectors !
Environmental
• Operating temperature: -40°C to + 105°C
• Sealing (mated/unmated): Dynamic IP68 - under
water for 1 week, 1 bar
Dynamic IP69K per DIN 40050
• Salt spray: 500 hours
• RoHS compliant & conform to the Chinese standard
SJ/T1166-2006 (Chinese RoHS equivalent)
• UV resistant:
No mechanical degradation or important variation of color
after 5 years of exposure in natural environment (equivalence
exposure to sun and moisture as per ISO4892)
Material
• Housing + Backshell: Thermoplastic UL94-V0
• Insert: Elastomer
• Contacts: Copper alloy - gold plated
Other platings on request
Technical characteristics
Mechanical
• Durability: 250 matings & unmatings
• Vibration resistance: Sinusoidal vibrations per
CEI 60512-4 - from 10 to 2000 Hz
• Thermal shock: 5 cycles 30 min. from -40°C to 105°C
per MIL-STD1344 method 1003
Electrical
• Current per contact max.: Size 16: 13A
Size 20: 7.5A
• Insulation resistance: ≥ 5000 MΩ under 500Vcc at 25°C
• Test potential: 1500 Veff between contacts size 20
2300 Veff between contacts size 16
according to MIL-DTL-26482
• Working voltage: 600 V - contacts size 20
1000 V - contacts size 16
according to MIL-DTL-26482
Connector family UTS
UTS 7
6 -
JC
8
8 E
E 2
2 P
S -
-
Body variation
6 Cable plug + backshell
7 Jam nut receptacle
0 Square flange receptacle
Backshell : JC = Backshell (only for plug) / No digit = No backsell (only for plug)
Shell size : 8, 10, 12, 14, 18
Contact type
E = Handsolder contacts / R = Crimp contacts* / D = PC tail contacts*
Insert arrangement - see next page
Contact gender : P = Pin contacts / S = Socket contacts
Insert rotation : No digit = Normal / W, X, Y, Z = Different orientations - see page 60
Ordering information
