Jam nut receptacle for pin contacts
suitable for rear panel mounting
Jam nut receptacle for socket contacts
suitable for rear panel mounting
Dimensions in millimetres
SHELL SIZE
10
12
14
16
18
20
22
24
No. OF WAYS
6
10
19
26
32
41
55
61
PART NUMBER
UT0W7106PH
UT0W71210PH
UT0W71419PH
UT0W71626PH
UT0W71832PH
UT0W72041PH
UT0W72255PH
UT0W72461PH
A
14.9
19.0
22.2
25.3
28.5
31.7
34.9
38.0
D MAX
31.7
31.7
31.7
31.7
31.7
33.3
33.3
33.3
F MAX
3.2
3.2
3.2
3.2
3.2
6.4
6.4
6.4
G
27.0
31.8
34.9
38.1
41.3
46.1
49.2
52.4
For IP68 add 6 to the end of the part number eg. UT0W7106PH6.
Dimensions in millimetres
SHELL SIZE
10
12
14
16
18
20
22
24
No. OF WAYS
6
10
19
26
32
41
55
61
PART NUMBER
UT0W7106SH
UT0W71210SH
UT0W71419SH
UT0W71626SH
UT0W71832SH
UT0W72041SH
UT0W72255SH
UT0W72461SH
A
14.9
19.0
22.2
25.3
28.5
31.7
34.9
38.0
D MAX
24.3
24.3
24.3
24.3
24.3
25.9
25.9
25.9
F MAX
3.2
3.2
3.2
3.2
3.2
6.4
6.4
6.4
G
27.0
31.8
34.9
38.1
41.3
46.1
49.2
52.4
For IP68 add 6 to the end of the part number eg. UT0W7106SH6.
