LT12daB LIgHT TOWeR • paRTs manuaL — Rev. #0 (06/03/11) — page 21
T-bAR ASSY.
nO. paRT nO. paRT name QTY. RemaRKs
1 10306 SCREW, HHC 1/2-13 X 4 1/2 2
2 13211 WASHER, FLAT 1/2 IN. USS 8
3 10176 NUT, NYLOC 1/2-13 4
7 11505 CLAMP 1
9 3254 TERMINAL, RING 16-14 3/8 IN. 1
11 06503-026 SCREW, HHC 1/2-13 X 3-1/4 IN. 2
13 29781 TEE-BAR, LIGHT MOUNT, MLT/DLT SPERO 1
14 29168 RECEPTACLE ASSY 4
15 19687 CRIMP, SLEEVE (30-410) 7
16 19688 INSULATOR, SPLICE CAP (2007) 7
18 19945 PLATE, T-BAR WIRING COVER 1
19 19944 GASKET, T BAR 1
20 29046 SCREW, PHPM 10-32 X 3/8 IN. ZINC 7
21 29047 DECAL, HIGH VOLTAGE 1
22 19972 REFLECTOR, RED, PETERSON #B491R 1
