LT12daB LIgHT TOWeR • paRTs manuaL — Rev. #0 (06/03/11) — page 19
WINCH ASSY.
nO.
paRT nO. paRT name
QTY.
RemaRKs
1#
DL205167 BOLT
1
2#
DL205055 WASHER
1
3#
DL404409 PAWL
1
4#
DL404166 SPACER
2
5#
DL204363 SPRING
1
6#
DL5240387 GEAR COVER, PAINTED BRONZE
1
6#
DL5240403 GEAR COVER, PLATED
1
8#
DL304755 REEL
1
9#
DL304221 ROPE CLAMP KIT
1
12#
DL204808 REEL SPACER
1
13#
DL404891 BASE
1
14#
DL204803 NUT
2
15#
DL404579 LOCKOUT LEVER
1
16#
DL204364 SPRING
2
17#
DL205127 BOLT
1
18#
DL204009 BUSHING
1
19#
DL205116 E-RING
1
20#
DL304760 DRIVE SHAFT
1
21#
DL204362 PRESSURE PLATE
1
22#
DL404164 RATCHET WHEEL
1
23#
DL404163 PRESSURE WASHER
1
24#
DL206328 BUSHING
1
25#
29793
HANDLE
1
26#
DL205033 NUT
1
27
29790
WINCH ASSEMBLY 1500A D-L .............................1 .........INCLUDES ITEMS W/#
