page 32 — LT12d50sa LIgHT TOWeR • paRTs manuaL — Rev. #1 (06/03/11)
BattErY assY.
CONNECT TO
STARTER
SOLENOID
RED
BLACK
1
2
4
5
6
2
3
7
CONNECT TO
ENGINE
GROUND
CONNECT TO
FRAME
