LT12d50sa LIgHT TOWeR • paRTs manuaL — Rev. #1 (06/03/11) — page 29
cOntrOl PanEl/Ballast assY.
nO. paRT nO. paRT name QTY. RemaRKs
1 0166 A WASHER, LOCK, 3/8 MED. 1
2 0205 SCREW, HHC 3/8-16 X 1 PLATED 1
3 0655 SCREW, HHC 5/16-18 1
4 1876 NUT, HEX FINISH 3/8-16 1
5 2574 GROMMET, 5/16" ID 7/16" OD 1
6 8133 SCREW, PHP 10-32 X 3/4 4
7 10019 NUT, NYLOC 10-32 .................................................................. 9 .............S/N 902625 AND BELOW
7 10019 NUT, NYLOC 10-32 .................................................................. 8 .............S/N 902626 AND ABOVE
8 12277 CLAMP, HOSE WORM 1-9/16 TO 2 SIZE 32 4
9 49048 SCREW, HHFS 1/4-20 X 3/4 G5 8
10% 19266 NUT, BLIND 1/4-20 X 10 GA 8
11 19297 LIGHT, PETERSON MFG V438 1
12 19968 TERMINAL BLOCK ( DC 70014 ) 2
13 29071 CONNECTOR, QUICK SCREW TERMINAL 4
14$ 5065 B SCREW, RHM #10-32 X 0.5 4
16 29603 SWITCH, MOMENTARY 1
20 29655 FITTING, STRAIN RELIEF HEYCO 3234 2
21 29656 LOCKNUT, NYLON 2
22 29712 BOLT, CARRIAGE 1/4-20 X 3/4 8
23 29796 CLAMP, CUSHIONED LOOP, 1-3/4 DIA X1 1
25 W29109 NUT, WING 3/8-16 1
28 49052 HARNESS, LT12D50SA 1
29 29675 WIRING KIT, LT-12 1
31 49070 NUT, FLANGED 1/4-20 SERATED PLTD 8
32 5283 NUT, NYLOC 5/16-18 1
33 29865 SNAP SWITCH PLATE ASSY. .................................................. 1 .............INCLUDES ITEMS W/%
34% 29864 SNAP FIT SWITCH INSERT 1
35% 29848 CIRCUIT BREAKER, 2 POLE, 30A SNAP FIT 1
36% 29847 CIRCUIT BREAKER, 1 POLE, 15A SNAP FIT 5
39 29798 BALLAST AND CAPACITOR, 230V 50 HZ ............................... 4 .............INCLUDES ITEMS W/@
41@ 0051475BH BALLAST CAPACITOR 30µF @440V 4
42 29719 SCREW HHC M5-.8 X 8MM PLATED, 8.8 DIN 8
43 29795 BRACKET, CONTROL PANEL 2
44 7245454 CONTROL PANEL, LOMBARDINI 1
45 50404900 KEYS, IGNITION, DOUBLE-SIDED 2
47 50384401 IGNITION SWITCH 1
48 GECAP35MF EXCITATION CAPACITOR 35µF @425V 1
49 29803 COVER, OUTLET, BLANK, WHITE #RCCBWH ....................... 2 .............INCLUDES ITEMS W/$
52 5065 B SCREW, RHM #10-32 X 0.5 .................................................... 5 .............S/N 902625 AND BELOW
53 29640 HOUR METER, SENDEC RECT FLUSH MOUNT .................. 1 .............S/N 904384 AND BELOW
54 1450 WASHER, FLAT #6 SAE ......................................................... 14 ............S/N 902625 AND BELOW
55 19819 SCREW, PHP #6-32 X 0.25 .................................................... 14 ............S/N 902625 AND BELOW
56 29761 MOUNTING PLATE, CONTROL PANEL .................................. 1 .............S/N 904384 AND BELOW
57 12851652 CONTROL PANEL.................................................................... 1 .............S/N 904384 AND BELOW
60 21611 SCREW THP 1/4-20 X 5/8 SS.................................................. 4 .............S/N 904384 AND BELOW
61 0948 WASHER, FLAT SAE 1/4 ......................................................... 4 .............S/N 904384 AND BELOW
62 29801 CIRCUIT BREAKER, 30A, 227V, SCREW .............................. 1 .............S/N 902625 AND BELOW
63 29376 CIRCUIT BREAKER, 15A, 227VAC KD1800 .......................... 1 .............S/N 902625 AND BELOW
64 29688 CIRCUIT BREAKER, 120VAC 10A DLT LIGHT ...................... 4 .............S/N 902625 AND BELOW
