Bard QTEC SERIES PACKAGED HEAT PUMP Q30H1 User Manual

Page 32

background image

Manual 2100-519
Page

32 of 42

FIGURE 22

QERV REMOVAL

MOUNTING
SCREWS

FRONT FILL

LOWER

BLOWER

ASSEMBLY

POWER

CONNECTOR

POWER

CONNECTORS
