Bard QTEC SERIES PACKAGED HEAT PUMP Q30H1 - Manual (Page 24)

Manual 2100-519
Page
24 of 42
7
D/YO
Orange
Red/White
Blue
9
W1/E
10
6
Temp. and Humidity
Controller
PART #8403-060
5
Black/White
G
O/B
3
Brown/White
11
8
4102-062
4
R
Y1
Plug #2
C
W2
1
Yellow
2
12
Red/Yellow
Purple
Brown
Orange
FIGURE 18
UNIT MOUNTED THERMOSTAT WIRING DIAGRAM
“A” THERMOSTAT OPTION
NOTE: On option X or A the CS2000A* (or other field
provided means to control ventilation) must be used
if any of the motorized ventilation options are
installed.
