GASOLINE ENGINE ASSY.
DFG-SERIES SURFACE GRINDERS
OPERATION AND PARTS MANUAL REV #3 (07/13/06)
PAGE 61
GASOLINE ENGINE ASSY.
NO. PART
NO. PART
NAME QTY. REMARKS
1
GX340
ENGINE, HONDA 11 H.P.
1
2
29018-021
MOUNT, GASOLINE ENGINE
1
3
29018-022
CLUTCH, PULLEY ASSY.
1
4 29018-023
ADAPTER,
M20 X 7/8-14 UNF
1
5
29018-024
CAP, OIL DRAIN
1
6
29018-025
KEY, SQUARE ¼” X ¼” X 2-1/2”
1
7
07898-005
SCREW, SET CUP POINT, 5/196-18 UNC X 5/16”
2
8
07030-007
WASHER, FLAT 7/16”, PLATED
1
9
07029-007
WASHER, LOCK 7/16”, PLATED
1
10
06502-012
SCREW, CAP 7/16-14 UNC X 1-1/2”, PLATED GDE. 5
1
11
06500-014
SCREW, CAP 5/16-18 UNC X 1-3/4”, PLATED GDE. 5
2
12
07030-005
WASHER, FLAT 5/16”, PLATED
2
13
07029-005
WASHER, LOCK 5/16”, PLATED
4
14
07033-005
NUT, HEXAGON 5/16-18 UNC, PLATED
2
15
06510-008
SCREW, CAP 5/16-24 UNF X 1” PLATED, GRADE 5
2
16
07033-006
NUT, HEXAGON 3/8-16 UNC, PLATED
6
17
07030-006
WASHER, FLAT 3/8” PLATED
6
18
29018-026
SCREW, CAP 3/8-16 UNC X 3/1/2”, FULL THD PLATED
2
19
07029-006
WASHER, LOCK 3/8”, PLATED
4
20 SFSG240317 SEAL,
ADAPTER
1
