ELECTRIC MOTOR ASSY.
DFG-SERIES SURFACE GRINDERS OPERATION AND PARTS MANUAL REV #3 (07/13/06) PAGE 59
ELECTRIC MOTOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 29018-027 MOUNT, ELECTRIC MOTOR 1
2 29018-028 MOTOR, ELECTRIC, 2 HP, 115/230 VAC, 60 HZ .............1...........P145K34FB18A
2 SF12136000 MOTOR, ELECTRIC, 3 HP, 230 VAC, 50/60 HZ 1
3 SFSG240500 PULLEY, DRIVE ................................................................1...........2 AND 3 HP 60 HZ MOTORS
3 SFSG240510 PULLEY, DRIVE ................................................................1...........3 HP 50 HZ MOTOR
4 10057-008 KEY, SQUARE 3/16” X 3/16” X 2” 1
5 29018-030 RELIEF, STRAIN 1
6 06500-008 SCREW, CAP 5/16-18 UNC X 1” PLATED 6
7 07030-005 WASHER, FLAT 5/16”, PLATED 6
8 07029-005 WASHER, LOCK 5/16”, PLATED 6
9 07033-005 NUT, HEXAGON 5/16-18 UNC, PLATED 6
10 29018-026 SCREW, CAP 3/8-16 UNC X 3-1/2” FULL THD PLT. 2
11 07898-005 SCREW, SET CUP POINT, 5/196-18 UNC X 5/16” 1
12 29018-031 NUT, BULKHEAD, INCLUDED W/REF. # 6 2
13 07030-006 WASHER, FLAT 3/8”, PLATED 6
14 07029-006 WASHER, LOCK 3/8”, PLATED 4
15 07033-006 NUT, HEXAGON 3/8-16 UNC, PLATED 6
16 29018-032 SWITCH, TOGGLE 115/230 VAC SELECTION 1
