CS7060 SERIES STOW SAW — PARTS MANUAL — REV. #6 (06/06/08) — PAGE 61
HYDRAULIC HOSES ASSY.
HYDRAULIC HOSES ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 37475 HOSE ASSEMBLY, #4 LP 1
2 37476 HOSE ASSEMBLY, #4 LP 1
3 37477 HOSE ASSEMBLY, #4 LP 1
4 37290 HOSE ASSEMBLY, #4 HP PARFLEX 1
5 37295 HOSE ASSEMBLY, #6-8 LP 1
6 37294 HOSE ASSEMBLY, #6 LP 1
7 37347 HOSE ASSEMBLY, #6 LP ....................................... 1 ................... SEE NOTE BELOW
8 37291 HOSE ASSEMBLY, #4 PARFLEX 1
9 37292 HOSE ASSEMBLY, #4 LP 1
10 37278 HOSE ASSEMBLY, #6 PARFLEX 1
11 37279 HOSE ASSEMBLY, #6 PARFLEX 1
12 37283 HOSE ASSEMBLY, #8 LP 1
13 37281 HOSE ASSEMBLY, #6 LP 1
14 37282 HOSE ASSEMBLY, #6 LP 1
15 37293 HOSE ASSEMBLY, #4 LP 1
16 37280 HOSE ASSEMBLY, DRIVE MOTOR CROSSOVER 1
FOR SAWS UP TO S/N ZD3700238 ONLY.
WHEN ORDERING THIS HOSE (P/N 37347 ITEM 7 ON
THIS PAGE), ALSO ORDER TWO (2) EACH FITTINGS
(P/N 11887, ITEM 22 SHOWN ON HYDRAULIC
FITTINGS AND CLAMPS ASSY).
