CS7060 SERIES STOW SAW — PARTS MANUAL — REV. #6 (06/06/08) — PAGE 49
LIFT BAIL ASSY.
LIFT BAIL ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
37114
SPACER, DEUTZ ENGINE LIFTING BRACKET
1
2
37115
BRACKET, DEUTZ ENGINE LIFTING ..................... 1 .................. SEE NOTE BELOW
3
940694
SCREW, HHC M10 - 1.5 X 30MM FT 10.9 NP
1
4
37314
SCREW, HHC M12 - 1.75 X 120MM TAP BOLT
1
5
37315
SCREW, HHC M12 - 1.75 X 120MM 10.9 NP
1
6
940358
WASHER, M10 X 21MM ZINC
1
7
933244
WASHER, FLAT SAE 1/2 GRD 9 YZ
3
8
933241
WASHER, FLAT SAE 5/16 GRD 9 YZ
1
9
16083
NUT, HEX M12 - 1.75 NO PLATE
1
10
06500-007
SCREW, HHC 5/16 - 18 X 7/8
1
TYPE 2 ROPE GUIDE SYSTEM SUPERCEDES TYPE 1
ROPE GUIDE SYSTEM. SEE FRONT POINTER ASSY.
