SP4030 MULTIQUIP SAW • PARTS MANUAL — REV. #3 (12/15/10) — PAGE 23
DEPTH INDICATOR/STOP SWITCH ASSY. (NEW STYLE)
NO. PART NO. PART NAME QTY. REMARKS
1@ 1618 NUT, NYLOC 10-24 1
2@ 12288 SCREW, THP 1/4-20 X 3/4 SS 2
3@# 19298 SCREW, PHP 6-32 X 3/8 2
4@# 21468 KNOB, PLASTIC 1/4-20 X 1 STUD 1
5@# 37240 PULLEY, CABLE .75 OD X .625 PITCH X .190 BORE 3
6@# 37241 SHAFT, DEPTH INDICATOR 2
7@# 37332 RING, 3/16 E-STYLE EXTERNAL 4
8@ 37404 SLEEVE, 3/64 ROPE DIA. COMPRESSION 2
9@ 37504 CABLE, 3/64 DIA, 7X19 STRAND NYLON COAT,4 FT 1
10@ 37527 SPRING, EXT. .625OD X 2.5L X .053 M WIRE 1
11@# 37603 POINTER, DEPTH STOP 1
12@ 38302 POINTER, SAW DEPTH INDICATOR 1
13@ 38306 SPACER, DEPTH STOP INDICATOR 1
15@ 560025 KNOB, SAW DEPTH INDICATOR 1
16@ 926149 SCREW, SHDLR 1/4D X 5/16L ,10-24,SCKT HD 1
17@# 38308 BUSHING, FLANGED .50 I.D. 3
18@# 38305 CAM, DEPTH STOP SWITCH 1
19@# 38303 SHAFT, DEPTH STOP INDICATOR 1
20@# 38301 ARM, DEPTH STOP POINTER W/A 1
21@# 38298 PULLEY, DEPTH INDICATOR 1
22@# 38297 BASE, 4030 DEPTH INDICATOR W/A 1
23@# 37766 SCREW, SHC 6-32 X 1.25 2
24@# 37679 SNAP RING, SH 87 3
25@# 37203 SWITCH, SNAP ACTION ROLLER PLUNGER POSITION 1
26@# 11152 NUT, NYLOC 6-32 2
27@# 1737 RING, SNAP, TRUARC 5100-50 3
28@# 1586 PIN, ROLL 1/8 x 3/4 1
29@# 1450 WASHER, FLAT SAE #6 2
30 38307 DEPTH STOP INDICATOR SUB ASSY. .................................. 1 ........ INCLUDES ITEMS W/#
31 38304 DEPTH INDICATOR ASSY ..................................................... 1 ........ INCLUDES ITEMS W/@
