SP4030 MULTIQUIP SAW • PARTS MANUAL — REV. #3 (12/15/10) — PAGE 21
NO. PART NO. PART NAME QTY. REMARKS
1@ 37598 BASE, 4030 SAW DEPTH INDICATOR 1
2@ 560025 KNOB, SAW DEPTH INDICATOR 1
3@ 110031 POINTER, CONCRETE SAW DEPTH 1
4@ 583059 SHIM, 0.375 OD X 0.25 ID X .020 THK 5
5@ 460019 FLANGE, BEARING 0.25 ID X 0.75 OD 3
6@ 37155 PULLEY, CABLE .75 OD 1
7@ 37240 PULLEY, CABLE .75 OD 2
8@ 10024 NUT, NYLOC 1/4 - 20 5
9@ 37622 STUD, 1/4 - 20 X 4" BLACK OXIDE 1
10@ 973752 SCREW, BHSC 1/4 - 20 X 5/8 SS 2
11@ 37241 SHAFT, DEPTH INDICATOR 2
12@ 37332 RING, 3/16 E-STYLE EXTERNAL 4
13@ 37404 SLEEVE, 3/64 ROPE DIA. COMPRESSION 2
14@ 37504 CABLE, 3/64 DIA, 7 X 19 STRAND NYLON COAT 1
15@ 926149 SCREW, SH SHLDR 1/2-20, 5/16 OD X 1/4 L 1
16@ 37736 CAM, DEPTH STOP POINTER 1
17@ 37600 ARM, W/A, 4030 DEPTH STOP POINTER 1
18@ 21468 KNOB, PLASTIC 1/4 - 20 X 1 STUD 1
19@ 37603 POINTER, DEPTH STOP 1
20@ 37605 SPACER, DEPTH INDICATOR POINTER 2
21@ 37203 SWITCH, SNAP ACTION ROLLER PLUNGER 1
22@ 37527 SPRING, EXT. .625 OD X 2.5L X .053 M WIRE 1
23@ 37766 SCREW, SHC 6-32 X 1.25 2
24@ 1450 WASHER, FLATSAE #6 2
25@ 11152 NUT, NYLOC 6-32 2
26 37597 DEPTH INDICATOR ASSY ...................................... 1 .................. INCLUDES ITEMS W/@
....................................................................................................... NO LONGER AVAILABLE
DEPTH INDICATOR/STOP SWITCH ASSY. (OLD STYLE)
