FCG16HA SAW • OPERATION AND PARTS MANUAL — REV. #1 (03/19/10) — PAGE 41
GUIDES ASSY.
GUIDES ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 # 20473 SCREW, HHC 3/8 - 16 X 3 FULL THRD 1
2 # 1456 NUT, HEX FINISH 3/8 - 16 4
3 # 1007 NUT, HEX JAM 3/8 - 16 4
4 # 25449 WHEEL, GUIDE 3.5 OD X .41 ID FCG 1
5 # 10133 NUT, NYLOC 3/8 - 16 1
6 25392 SHEET, REAR GUIDE ...................................................... 1 ......... NO LONGER AVAILABLE
7 # 3215 SCREW, HHC 1/2 - 13 X 3-1/2 1
8 # 36128 WASHER, NYLON 1/2" ID 4
9 # 10176 NUT, NYLOC 1/2 - 13 1
10 * 35476 SCREW, SHC 5/16-18 X 3.5 FULL THRD 1
11 * 21369 BEARING, SEALED 5/16 ID X 7/8 OD 2
12 * 21189 WHEEL, 2.13 OD X 1.25 W POLYURETHANE 1
13 * 21185 SPACER, 1/2 X 5/16 X 3/8 P33-3 1
14 * 21368 PLATE, POINTER (GUIDE) FCG 1
15 * 5283 NUT, NYLOC 5/16-18 2
16 * 0161 D NUT, HEX FINISH 5/16-18 2
17 * 35096 SASH ASSY., WIRE ROPE 1
18 * 19470 WASHER, FLAT 5/16 USS 1
19 * 35093 ARM, FRONT POINTER (GUIDE) W/A, FCG 1
20 35097 POINTER (GUIDE) ASSY., WHEEL STYLE .................... 1 ......... INCLUDES ITEMS W/ *
21 25416 GUIDE, REAR ASSY. ....................................................... 1 ......... NO LONGER AVAILABLE
21 38362 GUIDE, REAR ASSY. ....................................................... 1 ......... FEB, 2010
....................................................................................................... INCLUDES ITEMS W/ #
22 * 0205 SCREW, HHC 3/8 - 16 X 1.0 2
23 * 0202 SCREW, HHC 5/16 - 18 X 1 ZINC 1
24 # 38365 MAGNET, FCG REAR ARM 1
25 # 19847 RIVET, POP, ALUM, 3/16X1/8-1/4 GRIP 2
26 # 38366 ARM, REAR POINTER WHEEL 1
27 10133 NUT, NYLOC 3/8 - 16 2
