FCG16HA SAW • OPERATION AND PARTS MANUAL — REV. #1 (03/19/10) — PAGE 15

Figures 3 shows the location of the basic controls or components,
for the FCG16HA Concrete Saw. Listed below is a brief
explanation of each control or component

1.

Hand Grips/Handlebar – When operating the saw, place
both hands on each grip to maneuver the saw.

2.

Adjustable Handle – Set to comfortable operating position.

3.

Rear Guide – Rear guide wheel drops into cut to assist in
straight tracking.

4.

Air Filter – Prevents dirt and debris from entering the engine
air intake. Keep cleaned and replace when necessary.

5.

Recoil Starter Handle – Pull to engage and start the
engine.

6.

Recoil Starter Assembly – Engages the engine when
the handle is pulled and rewinds the starter rope when the
handle is released.

7.

Wheels/Carraige Assembly – Heavy-duty polyurethane
wheels with permanently sealed ball bearings.

COMPONENTS

8.

Diamond Blade – 0.675" (15.9 mm) Arbor diameter. 10"
blade capacity. 10" diameter provides for 1/4" to 3 1/4"
depth of cut. MAX Width blade is .375" (9.5 mm).

9.

Blade Guard – Covers saw blade and flips up to allow
blade to be changed.

10. Belt Tension Adjuster – Adjusts belt tension.

11. Front Pointer – Assists in straight tracking.

12. Front Pointer Arm – Pivots up for storage and pivots down

for use.

13. Depth Adjust Disk – Turn disk clockwise or counter-

clockwise to adjust the cutting depth up or down.

14. Fuel Tank – Use unleaded gasoline. Do not overfill.

15. Shift Knob – Moves Depth Stop Rod in or out of keyhole

slot.

16. V-Belt Cover – Remove this cover to gain access to the V-

belt. NEVER operate the saw with this cover removed.

17. Arbor Shaft Grease Zerks – Conveniently located for

lubrication.

18. On/Off Switch (Engine)– Turn to the "ON" position to

allow engine to be started and turn to the "OFF" position to
prevent accidental starting.

19. Handle Lock – Lock handle height to a comfortable

operating position.

20. Screw Plunger – Line up bottom edge of Depth Stop Rod

on Screw Plunger across from desired depth line mark.

21. Depth Stop Rod – Holds blade above working surface or

allows blade to cut into working surface at specified depth.

22. Engine Shut-off Switch – The Engine Shutdown Switch

located next to the handle lock serves both as an Emergency
Engine Shut-Off and as the primary Shutdown switch. This
allows the operator to shutdown the saw safely away from
moving parts.

23. Dust Collection – Provides for connection to suitable dust

collection bag or vacuum system.

24. Sash – Allows for the lowering and raising of the front

guide from the operator's position.
