BP-25H CE GASOLINE VIBRATOR — OPERATION MANUAL— REV. #4 (12/19/07) — PAGE 19
8. If the engine has started, slowly return the choke lever
(Figure 15) to the OPEN position. If the engine has not started
repeat steps 1 through 6.
Figure 14. Starter Grip
7. Grasp the starter grip (Figure 14) and slowly pull it out. The
resistance becomes the hardest at a certain position, corre-
sponding to the compression point. Pull the starter grip briskly
and smoothly for starting.
Figure 15. Choke Lever (Open)
BP-25H CE GASOLINE VIBRATOR — INITIAL START-UP (ENGINE)
Starting the Engine
1. Place the engine fuel valve lever (Figure 9) to the "ON"
position.
Figure 9. Engine Fuel Valve Lever (ON Position)
2. Place the choke lever (Figure 10) in the " CLOSED " position
if starting a cold engine.
3. Place the choke lever (Figure 11) in the " OPEN " position
if starting a warm engine or the temperature is warm.
Figure 10. Engine Choke Lever (Closed)
Figure 11. Engine Choke Lever (Open)
This section is intended to assist the operator with the initial
start-up of the BP-25H CE vibrator. It is extremely important that
this section be read carefully before attempting to use the vibrator
in the field.
Figure 12. Ignition ON/OFF Switch (ON Position)
4. Place the Ignition ON/OFF switch (Figure 12) in the " ON
" position.
Figure 13. Throttle Grip (Idle/Turttle Position)
THROTTLE
GRIP
CCW ROTATION
DECREASES
ENGINE SPEED
(IDLE)
6. Turn the throttle grip CCW
to the “TURTTLE” position
(Figure 13) to start the en-
gine in the idle mode.
