b46S90 WaLK-beHIND TROWeL • OpeRaTION aND paRTS maNUaL — Rev. #0 (06/13/13) — page 13

engine specifications

Table 3. engine Specifications/Dimensions

model

Subaru eX270De5013 engine

Type

Air-cooled 4 stroke, Slant Single Cylinder, OHC,

Horizontal PTO Shaft Gasoline Engine

Bore X Stroke

2.95 in. X 2.36 in. (75 mm x 60 mm)

Displacement

16.17 cu-in. (265 cc)

Max. Output

9.0 H.P. @ 4000 RPM

Fuel Tank Capacity

Approx. 1.59 U.S. Gallons (6.1 Liters)

Fuel

Unleaded Gasoline

Lube Oil Capacity

1.0 qt. (1.0 liters)

Oil Type

4-Stroke API, SF or SG

SAE 10W-30 General Use

Speed Control Method

Centrifugal Fly-weight Type

Cooling System

Forced Air

Starting Method

Recoil Start

Spark Plug Type

NKG BR6HS

Spark Plug Gap

0.028-0.031 in. (0.70 - 0.80 mm)

Dimension (L x W x H)

13.82 x 16.54 X 16.14 in. (351 X 420 X 410 mm)

Dry Net Weight

46.31 lbs (21 Kg.)
