pagE 30 —HTXD6i RIDE-ON TROWEL • paRTs maNuaL — REv. #2 (10/21/13)
PIVOT aSSy.
TIGHTENING SEQUENCE
1
2
3
4
6
8
7
5
1
2
3
4
5
6
8
7
10
9
12
13
14
15
18
16
20
22
23
8
13
13
17
17
19 21
RIGHT
LEFT
APPLY BLUE LOCTITE #246 x 8 1
APPLY BLUE LOCTITE #246 x 12 2
APPLY MINIMAL AMOUNT OF LPS ANTI-SEIZE GREASE TO THREADS OF SCREW (ITEM 18).
HAND START SCREWS. FOLLOWING TIGHTENING SEQUENCE (SEE DIAGRAM ABOVE).
TORQUE SCREW ASSEMBLY (FIRST PASS) TO A VALUE OF 21 FT-LBS (28.47 N.m). FOLLOW
SAME SEQUENCE FOR FINAL TORQUE OF 41 FT-LBS (55.59 N.m).
CLEAN WITH NON-PETROLEUM BASE CLEANER BEFORE INSTALLING ITEMS 9 AND 10.
3
4
NOTES:
1
2
3
BLUE
LOCTITE
24
4
9
4
10
9
9
10
SEAL
KIT
25
